(備忘録-python)LightGBMをOptunaで調整する方法(分類)

import matplotlib.pyplot as plt
%matplotlib inline
import japanize_matplotlib
import pandas as pd

import seaborn as sns
import numpy as np

from sklearn.metrics import (
    confusion_matrix,
    accuracy_score,
    precision_score,
    recall_score,
    f1_score
)

import lightgbm as lgb
import optuna

from sklearn.ensemble import RandomForestClassifier
from sklearn.metrics import fbeta_score
from sklearn.model_selection import train_test_split

def heat_map(cm):
    cm_matrix = pd.DataFrame(data=cm,columns=['Actual Positive:1','Actual Negative:0'],
                            index=['Predict Positive:1','Predict Negative:0'])

    # ヒートマップで描画
    plt.figure(figsize=(3, 3))
    heatmap = sns.heatmap(cm_matrix, annot=True, fmt='d',cmap='coolwarm')
    # heatmap.set_title('混同行列',fontsize=20)
    heatmap.set_xticks([0.5,1.5])
    heatmap.set_xlabel('予測',fontsize=15)
    heatmap.set_xticklabels(['Negative:0','Positive:1'],fontsize=12)
    heatmap.set_ylabel('真値',fontsize=15)
    heatmap.set_yticks([0.5,1.5])
    heatmap.set_yticklabels(['Negative:0','Positive:1'],fontsize=12)

TRAIN_df=学習データ
VALID_df=検証データ

x_train=TRAIN_df[利用するカラム]
x_valid=VALID_df[利用するカラム]

target_columns=目的変数のカラム
y_train=TRAIN_df[target_columns]
y_valid=VALID_df[target_columns]

# train_test_split
X_tr, X_te, y_tr, y_te = train_test_split(x_train,y_train,random_state=42,stratify = y_train)

def objective(trial):

    lgb_train = lgb.Dataset(X_tr, y_tr)
    lgb_test = lgb.Dataset(X_te, y_te, reference=lgb_train)

    param = {
        'task': 'train',
        'boosting_type': 'gbdt',
        'objective': 'binary',
        'metric': {'binary_error'},#binary_error

        'lambda_l1'         : trial.suggest_float('lambda_l1', 1e-8, 10.0, log=True),
        'lambda_l2'         : trial.suggest_float('lambda_l2', 1e-8, 10.0, log=True),
        'learning_rate': trial.suggest_float('learning_rate', 0.1, 1.0),
        'num_leaves': trial.suggest_int('num_leaves', 2, 256),
        'feature_fraction': trial.suggest_float('feature_fraction', 0.4, 1.0),
        'bagging_fraction': trial.suggest_float('bagging_fraction', 0.4, 1.0),
        'bagging_freq': trial.suggest_int('bagging_freq', 1, 7),
        'min_child_samples': trial.suggest_int('min_child_samples', 5, 100),

        'force_col_wise':True,
        'random_state': 0,
        }


    model = lgb.train(
                    params=param,                    # ハイパーパラメータをセット
                    train_set=lgb_train,              # 訓練データを訓練用にセット
                    valid_sets=[lgb_train, lgb_test], # 訓練データとテストデータをセット
                    valid_names=['Train', 'Test'],    # データセットの名前をそれぞれ設定
                    num_boost_round=100,              # 計算回数
                    callbacks=[lgb.early_stopping(stopping_rounds=50, verbose=1),
                               lgb.log_evaluation(10),],         # アーリーストッピング設定

                    # evals_result=lgb_results,
                    # verbose_eval=-1,                  # ログを最後の1つだけ表示
                    )

    # 推論
    pred = model.predict(X_te, num_iteration=model.best_iteration)
    y_pred = np.where(pred < 0.5, 0, 1) # 0.5より小さい場合0 ,そうでない場合1を返す

    # 評価
    #＝＝＝＝＝＝＝＝＝＝＝利用したい評価指標に変更＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝
    score = fbeta_score(y_te, y_pred, average='binary', beta=0.5)

    return score

study = optuna.create_study(direction='maximize',sampler=optuna.samplers.TPESampler(seed=42))
study.optimize(objective, n_trials=200)

print("=======ベストパラメータ========")
print(study.best_params)

lgb_train = lgb.Dataset(X_tr, y_tr)
lgb_test = lgb.Dataset(X_te, y_te, reference=lgb_train)

param = {
    'task': 'train',
    'boosting_type': 'gbdt',
    'objective': 'binary',
    'metric': {'binary_error'},#binary_error
    'force_col_wise':True,
    'random_state': 0,
    }
param.update(study.best_params)


model = lgb.train(
                # **study.best_params,              # ハイパーパラメータをセット
                params=param,


                train_set=lgb_train,              # 訓練データを訓練用にセット
                valid_sets=[lgb_train, lgb_test], # 訓練データとテストデータをセット
                valid_names=['Train', 'Test'],    # データセットの名前をそれぞれ設定
                num_boost_round=100,              # 計算回数
                callbacks=[lgb.early_stopping(stopping_rounds=50, verbose=1),
                           lgb.log_evaluation(10),],         # アーリーストッピング設定

                # evals_result=lgb_results,
                # verbose_eval=-1,                  # ログを最後の1つだけ表示
                )


# prediction
pred = model.predict(X_te, num_iteration=model.best_iteration)
y_pred = np.where(pred < 0.5, 0, 1) # 0.5より小さい場合0 ,そうでない場合1を返す

pred_val = model.predict(x_valid, num_iteration=model.best_iteration)
y_pred_val = np.where(pred_val < 0.5, 0, 1) # 0.5より小さい場合0 ,そうでない場合1を返す


valid_precision=precision_score(y_valid,y_pred_val)
valid_recall=recall_score(y_valid,y_pred_val)
valid_f1=f1_score(y_valid,y_pred_val)

print(valid_precision,valid_recall,valid_f1)

# cm = confusion_matrix(y_valid,y_pred_val)
cm = confusion_matrix(y_pred=y_pred_val,y_true=y_valid)
heat_map(cm)
plt.xticks(rotation=90)
plt.show()

plt.rcParams["font.size"] = 8
lgb.plot_importance(model, height = 0.5, figsize = (4,8),)
